Product Overview

The myFanimation mix-and-match offering puts design into the hands of customers as you select a motor, blades, fitters and glass to build your own fan. The fan includes Fanimation's latest innovations such as Hang Right? and Fan Shield?, which help to minimize vibration and eliminate noise, respectively. The design also brilliantly conceals screws so all eyes can be on your beautiful design. And, with its tri-mount feature, the Distinction fan can be easily installed one of three ways: flush-mount, standard or slope.

The myFanimation mix-and-match offering puts design into the hands of customers as you select a motor, blades, fitters and glass to build your own fan. The fan includes Fanimation's latest innovations such as Hang Right? and Fan Shield?, which help to minimize vibration and eliminate noise, respectively. The design also brilliantly conceals screws so all eyes can be on your beautiful design. And, with its tri-mount feature, the Distinction fan can be easily installed one of three ways: flush-mount, standard or slope.

Energy Information at High Speed

Airflow:

6823 Cubic Feet per Minute

Electricity Rate:

73 Watts (excluded lights)

Airflow Efficiency:

94 Cubic Feet Per Minute Per Watt

Standard Information

Category:

Fans

Subcategory:

Fan Motor Without Blades

Finish:

White

Style:

Traditional

Option:

Damp Rated

Number of Blades:

5 Blades

Refinement Options

Category:

Fan-Multi

Finish:

Matte White

Option:

Damp

Family:

Myfanimation

Voltage:

120 V

Additional Info:

BTT9R Bluetooth hand-held remote included

Air Flow CFM:

6823

Air Flow Efficiency:

94

Amperage:

0.6

Blade Pitch:

14

Canopy:

6.34 Dia x 2.83 H

Diameter:

12.98

Down Rod Included:

4.5

Electricity Used:

73

Harmonized Codes:

8414.51.3000

Length:

14.76

Light Kit Included:

No

Motor Fan Speed:

3

Motor RPM:

98

Motor Size:

212 X 25

Motor Type:

AC

Remote Control Included:

BTT9R

Ship Carton Height:

11.73

Ship Carton Length:

14.76

Ship Carton Width:

14.76

Ship Weight:

28.18

Sold By:

Each

Warranty:

Limited Lifetime

Weight:

28.18

Airflow Efficiency Low:

179

Airflow Efficiency Medium:

130

Avg Airflow Efficiency:

14

Avg CFM Energy:

717

Avg Energy Use Watts:

45

Avg Estimated Yearly Energy Cost:

13

Avg Estimated Yearly Energy Cost on HIGH:

20

Canopy Diameter:

6.34 Dia

Canopy Height:

2.83 H

Cap Included:

No

Carton Cubic Feet:

1.48

Cartons Per Unit:

1

Case Height:

11.73

Case Length:

14.76

Case Quantity:

1

Case Weight Pounds:

28.18

Case Width:

14.76

CEC Uploaded:

Yes

Ceiling To Blade Edge:

12.78

Ceiling To Bottom:

14.2

CFM Low:

2147

CFM Medium:

4612

Compatible Accessories:

APG245BL, DR1-12MW, DR1-18MW, DR1-24MW, DR1-36MW, DR1-48MW, DR1-60MW, DR1-72MW, DR1-CPMW, SCK1-52MW

Compatible Blades:

B160CY, B160DWA, B160MW, B160WA, B160WE, B172CY, B172DWA, B172MW, B172WA, B172WE, B260CY, B260DWA, B260MW, B260WA

B272CY, B272DWA, B272MW, B272WA, B360CY, B360DWA, B360MW, B360WA, B372CY, B372DWA, B372MW, B372WA, B460CYN, B460WADWA, B472CYN, B472WADWA, B560DWA, B560MW, B660DWA, B660MW, B760DWA, B860DC, B860MW

Compatible Controls:

BTT9, C4, CRL4WH, CRL8TS

Compatible Light Kits:

F1MW, F2MW, F3MW, F4MW

Compatible Wall Controls:

C21, CW1LA, CW1SWLA, CW1SWWH, CW1WH, CW2LA, CW2WH, CW5LA, CW5WH, CW60WH

Country of Origin:

China

Current Draw High:

0.6

Current Draw Low:

0.24

Current Draw Medium:

0.42

Damp Rated:

Yes

DOE Classification:

LSSD

DOE-FTC Uploaded:

Yes

DOEFTC Uploaded:

Yes

Downrod Length:

4.5

Exempt from DOE Procedure:

No

Fan Energy Star:

No

Housing Diameter:

12.98

Included Control:

BTT9R

Included Control Type:

Handheld

Leadwire:

80

Max Ceiling Slope:

19

Max Watt:

73

Maximum Slope Degree:

19

Motor Reversible:

Yes

Number of Blades:

5

Number Of Speeds:

3

Regulated Product:

Yes

Reverse Switch Location:

Control

RPM High (VI):

98

RPM Low (II):

32

RPM Medium (IV):

64

Safety Rating:

UL Approved, cUL Approved

Voltage Cycles:

60 Hz

Watts Low:

12

Watts Medium:

36

BTT9R Bluetooth Hand-held Remote Included
