240W UFO LED High Bay; 33840 Lumens; 4000K; 277-480 Volt; 0-10V Dimmable; Black Finish
$320.50
Item Sales Info
Add To Wishlist
Compare Item
Email
Print
Availability
Manufacturer has 19 items available.
This Item has been Discontinued. Please verify product pricing and availability with vendor prior to submitting any orders.
Dimensions
Height: 8.58"
Width: 14.17"
Product Overview
240W UFO LED High Bay; 33840 Lumens; 4000K; 277-480 Volt; 0-10V Dimmable; Black Finish
Standard Information
Category:
Utility
Subcategory:
Other Utility
Finish:
Black
Style:
Traditional
Option:
LED
Prop 65
Refinement Options
Category:
Hi-Bay
Sub Category:
UFO
Style:
Utility
Avg Rated Hours:
50000
Bulb Shape1:
Integrated LED
Bulb Type1:
LED
Color Temperature:
Cool White
Diameter:
14.17
Dimmable:
Yes-Dimmable
Each Height:
8.07
Each Length:
16.54
Each Width:
16.54
Lumens:
33840L
Tariff Code:
9405.11.6020
Warranty:
5 Year Limited - Fixtures
Wire Length:
72
Amps:
0.866-0.500A
ANSI Base:
Integrated
BAA Compliant:
No
Beam Angle:
90
CA Prop-65:
Lead
CCT Selectable:
No
CEC:
T20 Exempt - Fixtures Not Regulated
CEC Terse:
Lawful for sale in California
CEC Web Text:
Lawful for sale
Connection:
Hardwire
Country Of Origin:
Malaysia
CRI:
80+
Dimmable Down To:
100 to 20 percent
Dimmable Function:
0-10V Dimming Only
DLC Classification:
Premium
DLC Primary Use:
High-Bay Luminaires for Commercial and Industrial Buildings
Each Cube:
1.2776
Each Quantity:
1
Efficacy:
141.00 LPW
FCC Compliant:
Yes
Feature 1:
Integrated Sensor Port
Feature 2:
IP65
Feature 3:
4KV Surge Protection
Feature 4:
6 Foot Whip
Feature 5:
90 degree Beam Angle
Feature 6:
50,000 Hours
Feature 7:
5 Year warranty
Finish Family:
Black
Has Driver:
Yes
HID Equiv:
700W
Housing Color:
Black
Impact Rating (IK):
IK08
Incandescent Equivalent:
2000W
Indoor Outdoor:
Indoor
IP Rating:
IP65
JA8 Compliant:
No
Lens Finish:
Clear
Lens Material:
Polycarbonate (PC)
Long Description:
Introducing 65-807, Satco's 240-watt, 277-480 volt, 4000K, black UFO LED High Bay. The superior value offered in our new commercial LED High Bay UFO's meets the needs of numerous applications. A few add-ons that are available for purchase for this
Material:
Die-Cast Aluminum
Mounting Procedure:
Ceiling
NSF Approved:
Yes
Operating Temp:
-40C (-40F) to +45C (+113F)
Order In Multiples Of:
1
Pack Type:
Box
Quantity In Pack:
1
Replaceable Light Source:
No
RoHS Compliant:
Yes
Romance Copy:
Introducing our newest generation of UFO high bays. These cULus listed products are offered in 4000K and 5000K in 100W, 150W, 200W and 240W (120-277V) in white and black finishes and 200W and 240W (277V-480V) in black. They feature an integrated sensor por
