Product Overview

10 Watt; LED Commercial Track Head; White; Cylinder; 36 Degree Beam Angle

Standard Information

Category:

Track Ltg.

Subcategory:

Track Heads

Finish:

White

Style:

Contemporary

Traditional

Option:

LED

Prop 65

Lumens:

450-800

Kelvin:

2501-3000

Refinement Options

Category:

Track Lighting

Sub Category:

Track Head

Style:

Contemporary

Avg Rated Hours:

50000

Bulb Shape1:

Integrated LED

Bulb Type1:

LED

Color Temperature:

Warm White

Dimmable:

Yes-Dimmable

Each Height:

7.87

Each Length:

2.76

Each Width:

2.56

Length:

5

Lumens:

600L

Tariff Code:

9405.11.6020

Warranty:

5 Year Limited - Fixtures

Amps:

0.083A

ANSI Base:

Integrated

BAA Compliant:

No

Beam Angle:

36

CA Prop-65:

Lead

CCT Selectable:

No

CEC:

California T24 2016 - 2022 JA8 Listed

CEC Terse:

Lawful for sale in California

CEC Web Text:

California T24 Listed

Country Of Origin:

China

CRI:

93+

Dimmable Down To:

100 to 20 percent

Dimmable Function:

120V only

Each Cube:

0.0322

Each Quantity:

1

Efficacy:

60.00 LPW

FCC Compliant:

Yes

Feature 1:

Sleek design, Rugged Construction

Feature 2:

White textured aluminum finish

Feature 3:

10W, 36 deg. Beam angle

Feature 4:

High CRI and R9 Values

Feature 5:

Superior LED performance

Feature 6:

Precise Beam Control

Feature 7:

Smooth Dimming Control

Finish Family:

White

Incandescent Equivalent:

60W

Indoor Outdoor:

Indoor

IOT Enabled:

No

JA8 Compliant:

Yes

Lens Material:

Polycarbonate (PC)

Long Description:

The new SATCO NUVO shotgun-style Pro Series LED track head offers a distinct look while providing superior illumination for high-demand applications. Built to withstand the demanding, everyday operation that comes with use in commercial settings while main

Material:

Die-Cast Aluminum

Mounting Procedure:

Track

Operating Frequency:

60Hz

Operating Temp:

-20C (-4F) to +40C (+104F)

Order In Multiples Of:

1

Pack Type:

Box

Power Factor:

0.92

Quantity In Pack:

1

R9 Value:

67

Replaceable Light Source:

No

RoHS Compliant:

Yes

Romance Copy:

The new SATCO NUVO shotgun-style Pro Series LED track heads offer a distinct look while providing superior illumination for high-demand applications. Built to withstand the demanding everyday operation that comes with use in commercial settings while maint

Safety Listing:

cETLus

SDS class:

LED_Fixture

Short Description:

TRACK PRO SERIES- 10W- WH- 36

Sloped Ceiling Compatible:

Yes

Temperature (CCT):

3000K

Title 20 Compliant:

Exempt

Title 24 Compliant:

Yes

Track Head Style:

Cylinder

Wattage Selectable:

No

Weight Lb.:

0.63
